Whitelisting AWS Load Balancers

One of the things not obvious how to do in Amazon EC2 is whitelisting traffic to your load balancers.

Here’s how to do it
In your security groups add the inbound traffic to security group “amazon-elb/amazon-elb-sg” for all TCP

Advertisements

Essential Knife Plugins for chef

Knife-Spork:
This plugin helps you control versioning of your cookbooks and also prevents you from accidently commiting things you don’t want to.

$ gem install knife-spork

https://github.com/jonlives/knife-spork

Knife-ec2:
Obviously this is a connector to ec2. I use Amazon ec2 so i am biased

$ gem install knife-ec2

https://github.com/opscode/knife-ec2/

Knife-preflight:
A preflight plugin for Chef::Knife which lets you see which nodes and roles use a particular cookbook before you upload it.

$ gem install knife-preflight

https://github.com/jonlives/knife-preflight

Knife-env-diff:
A plugin for Chef::Knife which will diff the cookbook versions of two or more environments.

$ gem install knife-env-diff

https://github.com/jgoulah/knife-env-diff

Other mentionables

Knife-slapchop:
Threaded bootstrapping of aws nodes
https://github.com/kryptek/knife-slapchop

Knife-ironfan
Cluster Deployments
https://github.com/infochimps-labs/ironfan

Search for more knife plugins:

$ gem search -r knife-

Multiple AWS Accounts with Knife Admin

I Recently stumbled across a predicament of multiple aws accounts.
This is a minor predicament but a predicament nonethless.
I have a situation where i have

1. A personal AWS account

2. A work AWS account

3. A vendor AWS account

These three AWS accounts all use the same chef-server. So to make my life easier i decided to organize them.
I created the following structure:

$ mkdir -p ~/chef-aws/{personal,work,thirdparty}/.chef

I copied my knife.rb from ~/.chef/knife.rb into each of these folders.

$ cp -p ~/.chef/knife.rb ~/chef-aws/personal
$ cp -p ~/.chef/knife.rb ~/chef-aws/work
$ cp -p ~/.chef/knife.rb ~/chef-aws/thirdparty

Here’s an example of the knife.rb file
You can find details on setting up knife with ec2 here : Knife-EC2 Configuration


current_dir = File.dirname(__FILE__)
log_level                :info
log_location             STDOUT
node_name                "neosirex"
client_key               "/home/James/.chef/myuser.pem"
validation_client_name   "neosirex-validator"
validation_key           "/home/James/.chef/random-validator.pem"
chef_server_url          "https://api.opscode.com/organizations/somemakebelieveaccount"
cache_type               'BasicFile'
cache_options( :path => "#{ENV['HOME']}/.chef/checksums" )
cookbook_path            ["#{current_dir}/../cookbooks"]

Here’s the snippet that’s added to each AWS specific knife.rb

knife[:aws_access_key_id] ='< AWS ACCESS KEY GOES HERE >'
knife[:aws_secret_access_key] ='< AWS SECRET KEY GOES HERE >'

So now in order to use different AWS accounts what i do is change into each of those aws directories and run knife commands from there.
Each of the following commands would give me the output only of the relevant AWS server

$ cd ~/chef-aws/personal && knife ec2 server list
$ cd ~/chef-aws/work && knife ec2 server list
$ cd ~/chef-aws/thirdparty && knife ec2 server list

I Leave my default ~/.chef/knife.rb file without AWS credentials in it.
This is because i don’t want to accidently deploy to the wrong AWS account.
There’s still room for human error but i suppose it’s better than nothing
If someone has a better approach to this i’d like to know about it.

Hash Keys and Values in General Ruby

Create a new Hash

node = Hash.new

Create a new Hash of Hash

node[:one] = Hash.new

Insert Values into your Hash of Hash

node[:one][:object] = "number1"
node[:one][:block] = "number2"

Print Key and Value

node[:one].each_pair do |k,v|
  puts k
  puts v
end

Print Keys only

node[:one].keys.each do |key|
  puts key
end

Print Values Only

node[:one].values.each do |value|
  puts value
end

Keys and Values from Hashes in Ruby Templates

Reference: http://ruby-doc.org/stdlib-1.9.3/libdoc/erb/rdoc/ERB.html
ERB recognizes certain tags in the provided template and converts them based on the rules below:

<% Ruby code -- inline with output %>
<%= Ruby expression -- replace with result %>
<%# comment -- ignored -- useful in testing %>
% a line of Ruby code -- treated as <% line %> (optional -- see ERB.new)
%% replaced with % if first thing on a line and % processing is used
<%% or %%> -- replace with <% or %> respectively

Create a new “motd” cookbook

$ knife cookbook create motd

Example: ~/cookbooks/motd/recipes/default.rb

#
# Cookbook Name:: motd
# Recipe:: default
#
# Copyright 2012, YOUR_COMPANY_NAME
#
# All rights reserved - Do Not Redistribute
#

template "/home/motd" do
  source "motd.erb"
  owner "root"
end

Example: ~/cookbooks/motd/template/default/motd.erb
* You can find out what hashes are defined on a system by running “ohai”

Hostname : <%= node["hostname"] %>
Platform : <%= node["platform"] %>

Memory Usage
<% node["memory"].each_pair do |k,v| %>
<%= k %>     : <%= v%>
<% end %>

Block Devices
<% node["block_device"].each_pair do |k,v| %>
Key: <%= k %>   -   <%= v%>
<% end %>

Network Info
<% node["network"]["interfaces"].keys.each do |k| %>
Key: <%= k %>
<% end %>

<% node["network"]["interfaces"].values.each do |v| %>
Value: <%= v %>
<% end %>

Run chef-client with the “motd” cookbook installed and look at the output at

$ cat /home/motd
Hostname: ubuntu01
Platform: ubuntu

Memory Usage
vmalloc_total     : 34359738367kB
anon_pages     : 129892kB
writeback     : 0kB
dirty     : 0kB
vmalloc_used     : 266104kB
vmalloc_chunk     : 34359469948kB
active     : 186264kB
buffers     : 31252kB
commit_limit     : 773540kB
nfs_unstable     : 0kB
slab_unreclaim     : 11684kB
bounce     : 0kB
slab_reclaimable     : 17644kB
mapped     : 11580kB
cached     : 190268kB
slab     : 29328kB
inactive     : 165136kB
free     : 105708kB
total     : 502612kB
committed_as     : 926460kB
page_tables     : 4324kB
swap     : cached0kBfree522236kBtotal522236kB

Block Devices
Key: sda   -   timeout30modelVMware Virtual Sremovable0vendorVMware,rev1.0size41943040staterunning
Key: sr0   -   timeout30modelVMware IDE CDR10removable1vendorNECVMWarrev1.00size1401432staterunning
Key: fd0   -   removable1size0
Key: loop7   -   removable0size0
Key: loop6   -   removable0size0
Key: loop5   -   removable0size0
Key: loop4   -   removable0size0
Key: loop3   -   removable0size0
Key: loop2   -   removable0size0
Key: loop1   -   removable0size0
Key: loop0   -   removable0size0
Key: ram15   -   removable0size131072
Key: ram14   -   removable0size131072
Key: ram13   -   removable0size131072
Key: ram12   -   removable0size131072
Key: ram11   -   removable0size131072
Key: ram10   -   removable0size131072
Key: ram9   -   removable0size131072
Key: ram8   -   removable0size131072
Key: ram7   -   removable0size131072
Key: ram6   -   removable0size131072
Key: ram5   -   removable0size131072
Key: ram4   -   removable0size131072
Key: ram3   -   removable0size131072
Key: ram2   -   removable0size131072
Key: ram1   -   removable0size131072
Key: ram0   -   removable0size131072

Network Info
Key: eth0
Key: lo

Value: mtu16436encapsulationLoopbackflagsLOOPBACKUPLOWER_U....< i truncated output >
Value: mtu1500typeethencapsulationEthernetflagsBROADCASTM....< i truncated output >

Also for shits and giggles
Example Ohai output:

root@ubuntu01:~# ohai
{
  "idletime": "35 minutes 35 seconds",
  "uptime": "36 minutes 47 seconds",
  "dmi": {
    "base_board": {
      "chassis_handle": "0x0000",
      "location_in_chassis": "Not Specified",
      "product_name": "440BX Desktop Reference Platform",
      "serial_number": "None",
      "manufacturer": "Intel Corporation",
      "version": "None",
      "type": "Unknown",
      "features": "None",
      "contained_object_handles": "0",
      "all_records": [
  .. < i truncated output >

Ubuntu/Debian Preseeding with LVM

When you have your ubuntu or debian splash screen hit “tab”
then append:

auto url=http://mywebserver/mypreseed.cfg

You can use this example to bring up a quick webserver to server your preseed file: Python Simple HTTP Server

You’ll still probably be prompted for all the locale information because that is requested BEFORE debian/ubuntu loads the preseed configuration. ( yes , dumb i know ). These are the settings that don’t get pulled in.

# keyboard and locale settings
####################################################################

d-i debian-installer/locale string en_US
d-i console-keymaps-at/keymap select sg-latin1

# networking
####################################################################

d-i netcfg/disable_dhcp boolean false
d-i netcfg/get_hostname string localhost
d-i netcfg/get_domain string localdomain
d-i netcfg/choose_interface select eth0

You can get around this by rebuilding your boot cdrom or doing a pxe install that loads all the info ahead of time.

Example

auto url=http://mywebserver/mypreseed.cfg \
locale=en_US console-keymaps-at/keymap=sg-latin1 \
interface=eth0 hostname=localhost domain=localdomain --

Now for actually making your preseed config

Setup Locale info

d-i     debian-installer/locale string en_US
d-i     console-setup/ask_detect boolean false
d-i     time/zone string UTC
d-i     debian-installer/splash boolean false
d-i     debian-installer/language string en
d-i     debain-installer/country string US
d-i     console-keymaps-at/keymap select sg-latin1

Setup Your Networking

d-i     netcfg/get_nameservers  string 192.168.1.5
d-i     netcfg/get_ipaddress    string 192.168.1.10
d-i     netcfg/get_netmask      string 255.255.255.0
d-i     netcfg/get_gateway      string 192.168.1.1
d-i     netcfg/confirm_static   boolean true
d-i     netcfg/get_hostname string tempnode
d-i     netcfg/get_domain string localdomain

Setup your Repository and what directory in the repo to look for your install files

d-i     mirror/country string manual
d-i     mirror/http/hostname string http.us.debian.org
d-i     mirror/http/directory string /debian
d-i     mirror/http/proxy string

Partition Your disks and set them up as lvm

d-i partman-auto/disk string /dev/sda
d-i partman-auto/method string lvm
d-i partman-lvm/device_remove_lvm boolean true
d-i partman-lvm/device_remove_lvm_span boolean true
d-i partman-auto/purge_lvm_from_device  boolean true
d-i partman-auto-lvm/new_vg_name string system

Setup your logical Volumes in LVM and also non-lvm partitions
This will make
* BEWARE OF YOUR FORMATTING OF THIS PART – IT IS SUPER SENSITIVE

/boot : is a bootable filesystem with 300mb and ext3
/ : Is between 10GB and grows to the end of the disk and ext3
swap : uses 200% of the size of system ram for a disk or 8GB

#d-i partman-auto/init_automatically_partition \
#  select Guided - use entire disk and set up LVM
d-i partman-auto/expert_recipe string                         \
      boot-root ::                                            \
              40 300 300 ext3                                 \
                      $primary{ }                             \
                      $bootable{ }                            \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext3 }    \
                      mountpoint{ /boot }                     \
              .                                               \
              2000 10000 1000000000 ext3                      \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext3 }    \
                      mountpoint{ / }                         \
              .                                               \
              8000 8000 200% linux-swap                       \
                      $lvmok{ }                               \
                      method{ swap } format{ }                \
              .

Here’s another LVM Example

d-i partman-auto/expert_recipe string                         \
      boot-root ::                                            \
              40 300 300 ext4                                 \
                      $primary{ }                             \
                      $bootable{ }                            \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext4 }    \
                      mountpoint{ /boot }                     \
              .                                               \
              2000 10000 1000000000 ext4                      \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext4 }    \
                      mountpoint{ / }                         \
              .                                               \
              2000 1000 10000 ext4                            \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext4 }    \
                      mountpoint{ /var }                      \
              .                                               \
              2000 1000 60000 ext4                            \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext4 }    \
                      mountpoint{ /var/lib/mysql }                      \
              .                                               \
              2000 1000 30000 ext4                            \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext4 }    \
                      mountpoint{ /www }                      \
              .                                               \
              8000 8000 200% linux-swap                       \
                      $lvmok{ }                               \
                      method{ swap } format{ }                \
              .

Answer yes to all the partition and LVM prompts

d-i partman-lvm/confirm boolean true
d-i partman/confirm_write_new_label boolean true
d-i partman/choose_partition select Finish partitioning and write changes to disk
d-i partman/confirm boolean true

Setup your Time Zone info

d-i     clock-setup/utc boolean true
d-i     clock-setup/ntp boolean true
d-i     clock-setup/ntp-server  string ntp.ubuntu.com
d-i     time/zone string US/Los_Angeles

Setup Root and First User info

d-i     base-installer/kernel/image     string linux-server
d-i     passwd/root-login       boolean true
d-i     passwd/root-password-crypted    password $1$VuPOoDRD$seX.C54E8TUdMkaAmKvjx0
d-i     passwd/user-fullname string Ubuntu User
d-i     passwd/username string ubuntu
d-i     passwd/user-password-crypted password $1$NvFY8IuR$BGqOozSN91ljvQB.pVLDw.
d-i     user-setup/encrypt-home boolean false
d-i     user-setup/allow-password-weak  boolean true
d-i     passwd/user-default-groups      string adm cdrom dialout lpadmin plugdev sambashare

Miscellaneous Stuffage

d-i     apt-setup/services-select       multiselect security
d-i     debian-installer/allow_unauthenticated  string true
d-i     pkgsel/upgrade  select safe-upgrade
d-i     pkgsel/language-packs   multiselect
d-i     pkgsel/update-policy    select none
d-i     pkgsel/updatedb boolean true
popularity-contest popularity-contest/participate boolean false
tasksel tasksel/first multiselect standard, openssh-server
d-i     grub-installer/skip     boolean false
d-i     lilo-installer/skip     boolean false
d-i     grub-installer/only_debian      boolean true
d-i     grub-installer/with_other_os    boolean false
d-i     finish-install/keep-consoles    boolean false
d-i     finish-install/reboot_in_progress       note
d-i     cdrom-detect/eject      boolean true
d-i     debian-installer/exit/halt      boolean false
d-i     debian-installer/exit/poweroff  boolean false

Choose your packages to install

d-i     pkgsel/include string vim openssh-server

What it looks like as one file:

d-i     debian-installer/locale string en_US
d-i     console-setup/ask_detect boolean false
d-i     time/zone string UTC
d-i     debian-installer/splash boolean false
d-i     debian-installer/language string en
d-i     debain-installer/country string US
d-i     netcfg/get_nameservers  string 192.168.1.5
d-i     netcfg/get_ipaddress    string 192.168.1.10
d-i     netcfg/get_netmask      string 255.255.255.0
d-i     netcfg/get_gateway      string 192.168.1.1
d-i     netcfg/confirm_static   boolean true
d-i     netcfg/get_hostname string tempnode
d-i     mirror/country string manual
d-i     mirror/http/hostname string http.us.debian.org
d-i     mirror/http/directory string /debian
d-i     mirror/http/proxy string
d-i partman-auto/disk string /dev/sda
d-i partman-auto/method string lvm
d-i partman-lvm/device_remove_lvm boolean true
d-i partman-lvm/device_remove_lvm_span boolean true
d-i partman-auto/purge_lvm_from_device  boolean true
d-i partman-auto-lvm/new_vg_name string system
#d-i partman-auto/init_automatically_partition \
#  select Guided - use entire disk and set up LVM
d-i partman-auto/expert_recipe string                         \
      boot-root ::                                            \
              40 300 300 ext3                                 \
                      $primary{ }                             \
                      $bootable{ }                            \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext3 }    \
                      mountpoint{ /boot }                     \
              .                                               \
              2000 10000 1000000000 ext3                      \
                      $lvmok{ }                               \
                      method{ format } format{ }              \
                      use_filesystem{ } filesystem{ ext3 }    \
                      mountpoint{ / }                         \
              .                                               \
              8000 8000 200% linux-swap                       \
                      $lvmok{ }                               \
                      method{ swap } format{ }                \
              .

d-i partman-lvm/confirm boolean true
d-i partman/confirm_write_new_label boolean true
d-i partman/choose_partition select Finish partitioning and write changes to disk
d-i partman/confirm boolean true
d-i     clock-setup/utc boolean true
d-i     clock-setup/ntp boolean true
d-i     clock-setup/ntp-server  string ntp.ubuntu.com
d-i     time/zone string US/Los_Angeles
d-i     base-installer/kernel/image     string linux-server
d-i     base-installer/kernel/image     string linux-server
d-i     passwd/root-login       boolean true
d-i     passwd/root-password-crypted    password $1$VuPOoDRD$seX.C54E8TUdMkaAmKvjx0
d-i     passwd/user-fullname string Ubuntu User
d-i     user-setup/allow-password-weak  boolean true
d-i     user-setup/encrypt-home boolean false
d-i     passwd/user-default-groups      string adm cdrom dialout lpadmin plugdev sambashare
d-i     apt-setup/services-select       multiselect security
d-i     debian-installer/allow_unauthenticated  string true
d-i     pkgsel/upgrade  select safe-upgrade
d-i     pkgsel/language-packs   multiselect
d-i     pkgsel/update-policy    select none
d-i     pkgsel/updatedb boolean true
popularity-contest popularity-contest/participate boolean false
tasksel tasksel/first multiselect standard, openssh-server
d-i     grub-installer/skip     boolean false
d-i     lilo-installer/skip     boolean false
d-i     grub-installer/only_debian      boolean true
d-i     grub-installer/with_other_os    boolean false
d-i     finish-install/keep-consoles    boolean false
d-i     finish-install/reboot_in_progress       note
d-i     cdrom-detect/eject      boolean true
d-i     debian-installer/exit/halt      boolean false
d-i     debian-installer/exit/poweroff  boolean false
d-i     pkgsel/include string vim openssh-server

Info for this was stolen here ( Thanks ):
http://cptyesterday.wordpress.com/2012/06/17/notes-on-using-expert_recipe-in-debianubuntu-preseed-files/

Preseed Example files found here:

https://github.com/cookingclouds/Preseed

Knife EC2 Extension – Install and Use

Install

$ apt-get install -y libxslt-dev libxml2-dev
$ gem install knife-ec2
$ gem install net-ssh-multi

Get Your AWS Keys

Login to your AWS account at aws.amazon.com
Go to My Account/Console -> Security Credentials

Scroll Down to The Certificates and Secret Keys Menu and generate your new access keys as needed

Generate the Keypair associated with your new ec2 instances ( for ssh )

Create a new keypair. This should result in a pem file output to you. If you lose this file you will not be able to access any ec2 instances associated with it unless you have alternate accounts you can login with.

Configure

$ cd ~/.chef
$ vi knife.rb

Append the following to your knife.rb

### AWS Configuration ###

## The below lines allow you to use the ec2 api
knife[:aws_access_key_id] ='< AWS ACCESS KEY GOES HERE >'
knife[:aws_secret_access_key] ='< AWS SECRET KEY GOES HERE >'

## The below allow you to ssh into new ec2 instance that are associated with the keypair below
## You can alternately choose to specify the username and key location on the knife command line
# knife[:aws_ssh_key_id] ='james-aws'
# knife[:identity_file] ="/home/james/.ssh/james-aws.pem"

Test knife-ec2 command

bootstrap file squeeze.rb can be grabbed from here:
https://github.com/cookingclouds/bootstrap/

$ knife ec2 server list
$ knife ec2 server create -I ami-e00df089 -f t1.micro -Z us-east-1a -G "default_security" -k james-aws --ssh-key /home/james/.ssh/james-aws.pem --template-file /home/james/bootstrap/squeeze.rb

knife-ec2 command reference list

knife ec2 server create --help
knife ec2 server create (options)
    -Z, --availability-zone ZONE     The Availability Zone
    -A, --aws-access-key-id KEY      Your AWS Access Key ID
    -K SECRET,                       Your AWS API Secret Access Key
        --aws-secret-access-key
        --user-data USER_DATA_FILE   The EC2 User Data file to provision the instance with
        --bootstrap-version VERSION  The version of Chef to install
    -N, --node-name NAME             The Chef node name for your new node
        --server-url URL             Chef Server URL
    -k, --key KEY                    API Client Key
        --color                      Use colored output
    -c, --config CONFIG              The configuration file to use
        --defaults                   Accept default values for all questions
    -d, --distro DISTRO              Bootstrap a distro using a template
        --ebs-no-delete-on-term      Do not delete EBS volumn on instance termination
        --ebs-size SIZE              The size of the EBS volume in GB, for EBS-backed instances
    -e, --editor EDITOR              Set the editor to use for interactive commands
    -E, --environment ENVIRONMENT    Set the Chef environment
    -f, --flavor FLAVOR              The flavor of server (m1.small, m1.medium, etc)
    -F, --format FORMAT              Which format to use for output
    -i IDENTITY_FILE,                The SSH identity file used for authentication
        --identity-file
    -I, --image IMAGE                The AMI for the server
        --no-color                   Don't use colors in the output
    -n, --no-editor                  Do not open EDITOR, just accept the data as is
        --no-host-key-verify         Disable host key verification
    -u, --user USER                  API Client Username
        --prerelease                 Install the pre-release chef gems
        --print-after                Show the data after a destructive operation
        --region REGION              Your AWS region
    -r, --run-list RUN_LIST          Comma separated list of roles/recipes to apply
    -G, --groups X,Y,Z               The security groups for this server
    -S, --ssh-key KEY                The AWS SSH key id
    -P, --ssh-password PASSWORD      The ssh password
    -x, --ssh-user USERNAME          The ssh username
    -s, --subnet SUBNET-ID           create node in this Virtual Private Cloud Subnet ID (implies VPC mode)
        --template-file TEMPLATE     Full path to location of template to use
    -V, --verbose                    More verbose output. Use twice for max verbosity
    -v, --version                    Show chef version
    -y, --yes                        Say yes to all prompts for confirmation
    -h, --help                       Show this message

Graphite Install

*this assumes debian or ubuntu

Graphite Cookbook Install

$ git clone https://github.com/cookingclouds/cookbooks/tree/master/cc_graphite

I Know there is a cookbook for graphite in the opscode repo but it has dependencies.
This cookbook shouldn’t have dependencies and is also a lot more messy
Run after installing cookbook :

$ /opt/graphite/bin/carbon-cache.py start
$ cd /opt/graphite/webapp/graphite && python manage.py createsuperuser

Manual Install

Grab the sourcecode


$ wget https://launchpad.net/graphite/0.9/0.9.10/+download/graphite-web-0.9.10.tar.gz
$ wget https://launchpad.net/graphite/0.9/0.9.10/+download/carbon-0.9.10.tar.gz
$ wget https://launchpad.net/graphite/0.9/0.9.10/+download/whisper-0.9.10.tar.gz
$ wget https://launchpad.net/graphite/0.9/0.9.10/+download/check-dependencies.py

Install Whisper Database

$ ls |grep tar |while read i ; do tar xzvf $i ; done
$ apt-get -y install apache2 python-django python-django-tagging python-ldap python-memcache python-cairo
$ cd ~/whisper-0.9.10/
$ python setup.py install

Install Carbon

$ apt-get -y install python-twisted python-simplejson
$ cd ~/carbon-0.9.10/
$ python setup.py install
$ cd /opt/graphite/conf/
$ cp carbon.conf.example carbon.conf
$ cp storage-schemas.conf.example storage-schemas.conf
$ cd /opt/graphite/
$ ./bin/carbon-cache.py start

Install Graphite-web

$ cd ~/graphite-web-0.9.10/
$ python check-dependencies.py
$ python setup.py install
$ cp examples/example-graphite-vhost.conf /etc/apache2/sites-available/default
$ cp /opt/graphite/conf/graphite.wsgi.example /opt/graphite/conf/graphite.wsgi
$ mkdir /etc/apache2/run
$ apt-get -y install libapache2-mod-wsgi
$ /etc/init.d/apache2 reload
$ cd /opt/graphite/webapp/graphite/
$ python manage.py syncdb
$ chown -R www-data:www-data /opt/graphite/storage
$ cd /opt/graphite/webapp/graphite
$ cp local_settings.py.example local_settings.py
$ /etc/init.d/apache2 restart

Examples on how to send data to graphite

hostname = * you guessed it
test_001 = service name
1001 = value
$NOW = epoch time to input in graph

$ NOW=`date +%s` ; echo "hostname.test_001 1001 $NOW" |nc localhost 2003

or

$ cd /opt/graphite/examples
$ ./example-client.py
